中央處理器 |
|
記憶體容量 |
|
記憶體種類 | 3200/2933/2666 MHz ECC DDR4 RDIMM/LRDIMM |
晶片組 | Intel® C621A |
SATA | SATA3 (6Gbps); RAID 0/1/5/10 support |
網路 | Supports 10GBASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output |
IPMI 智慧平台管理介面 |
|
SATA | 10 SATA3 (6Gbps) ports |
NVMe | 2 M.2 Socket support NVMe/SATA |
LAN | 2 RJ45 10GBase-T ports 1 RJ45 Dedicated IPMI LAN port |
USB | 5 USB 3.0 ports (3 rear, 2 front, Type A) 1 USB 3.0 ports (Type C) |
Video | 1x VGA port |
4U Rackmountable / Tower Optional Rackmount Kit |
高度 | 18.2" (462mm) |
寬度 | 7.0" (178mm) |
深度 | 26.5" (673mm) |
重量 |
|
|
PCI-Express |
|
M.2 |
|
風扇 |
|
2x 2200W Redundant Power Supplies with PMBus | |
全部輸出電源 |
|
交流電輸入頻率 | 50-60Hz |
|
RoHS | RoHS Compliant |
環境規格 |
|
