處理器 | |
| 中央處理器 | |
| Dual Socket P+ (LGA-4189) | |
| 3rd Gen Intel® Xeon® Scalable processors | |
| Support CPU TDP 270W | |
| Up to 40 Cores | |
系統記憶體 | |
| 記憶體容量 | |
| 16 DIMM slots | |
| Up to 4TB 3DS ECC DDR4-3200MH RDIMM/LRDIMM | |
| Supports Intel® Optane™ DCPMM | |
| 記憶體種類 | 3200/2933/2666MHz ECC DDR4 RDIMM/LRDIMM |
內建裝置 | |
| 晶片組 | Intel® C621A chipset |
| SATA | SATA3 (6Gbps) with RAID 0, 1, 5, 10 |
| 網路 | Dual Port 10GbE from Intel X710 |
| IPMI 智慧平台管理介面 | |
| Support for Intelligent Platform Management Interface v.2.0 | |
| IPMI 2.0 with virtual media over LAN and KVM-over-LAN support | |
| 顯示晶片 | ASPEED AST2600 BMC |
輸入 / 輸出 | |
| SATA | 8 SATA3 (6Gbps) ports |
| LAN | |
| 2 RJ45 10GBase-T LAN ports | |
| 1 RJ45 Dedicated IPMI LAN port | |
| USB | |
| 2 USB 3.0 ports (rear) | |
| 2 USB 2.0 ports (front) | |
| Video | 1 VGA Connector |
外觀型態 | |
| 2U Rackmountable with Rail kit | |
尺寸與重量 | |
| 高度 | 3.46"(88mm) |
| 寬度 | 17.35"(440.7mm) |
| 深度 | 30.18"(766.8mm) |
| 重量 | |
| Net Weight: 39.5 lbs (17.9 kg) | |
| Gross Weight: 54 lbs (24.5 kg) | |
磁碟槽 / 存儲 | |
| 熱插拔 | 10x 2.5" hot-swap NVMe/SATA/SAS drive bays (4x 2.5" NVMe dedicated) |
擴充插槽 | |
| PCI-Express | |
| 6 PCI-E 4.0 x16 slots | |
| 2 PCI-E 4.0 x8 slots | |
系統散熱 | |
| 風扇 | 5x 8cm Heavy duty fans with optimal fan speed control |
電源供應器 | |
| 電源 | 2600W 1U Redundant Power Supplies with PMBus |
| AC Input | 2600W: 200-240Vac / 15A Max |
| DC Input | 2600W: 200-240Vdc For CQC Only/ 15A Max / 50-60Hz |
| +12V | Max: 216A / Min: 0A (11.4Vdc-12.6Vdc) (12V output) |
支援作業系統 | |
| OS | |
| Red Hat Enterprise Linux 8.4 | |
| Windows Server 2022 | |
| Windows Server 2019 | |
| VMware ESXi 7.0U2 | |
| Citrix Hypervisor 8.2 | |
作業環境 | |
| RoHS | 環境規格 |
| Environmental Spec. | |
| Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) | |
| Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) | |
| Operating Relative Humidity: 8% to 90% (non-condensing) | |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) | |
