處理器 | |
| 中央處理器 | |
| Dual AMD EPYC™ 7002/7003 Series Processors | |
| Socket SP3 | |
| Supports CPU TDP up to 240W | |
| Up to 128 Cores (64 per CPU) | |
系統記憶體 | |
| 記憶體容量 | |
| 16 DIMM slots | |
| Up to 4TB 3DS ECC DDR4-3200MH RDIMM/LRDIMM | |
| 記憶體種類 | 3200MHz ECC DDR4 RDIMM/LRDIMM |
內建裝置 | |
| 晶片組 | System on Chip (SoC) |
| SATA | SATA3 (6Gbps) |
| 網路 | 2 10GBase-T LAN ports (Intel X550-ATX) |
| IPMI 智慧平台管理介面 | |
| Support for Intelligent Platform Management Interface v.2.0 | |
| IPMI 2.0 with virtual media over LAN and KVM-over-LAN support | |
| 顯示晶片 | ASPEED AST2500 BMC |
輸入 / 輸出 | |
| SATA | 8 SATA3 (6Gbps) ports |
| LAN | |
| 2 RJ45 GBase-T LAN ports | |
| 1 RJ45 Dedicated IPMI LAN port | |
| USB | 4 USB 3.2 Gen1 ports |
| Video | 1 VGA Connector |
外觀型態 | |
| 2U Rackmountable with Rail kit | |
尺寸與重量 | |
| 高度 | 3.43"(87mm) |
| 寬度 | 17.25"(438.4mm) |
| 深度 | 32.71"(831mm) |
| 重量 | |
| Net Weight: 44.8 lbs (20.3 kg) | |
| Gross Weight: 73 lbs (33.1 kg) | |
磁碟槽 / 存儲 | |
| 熱插拔 | Up to 8x 3.5" SATA/NVMe drive bays |
擴充插槽 | |
| PCI-Express | |
| 4 FH/FL PCIe Gen 4.0 x16/x8 slots (MUX pairs with adjacent x8 slots) | |
| 4 FH/FL PCIe Gen 4.0 x0/x8 slots (MUX pairs with adjacent x16 slots) | |
| 2 Low Profile PCIe x16 Gen 4.0 slots | |
系統散熱 | |
| 風扇 | 5pcs 8cm Heavy duty fans with optimal fan speed control |
電源供應器 | |
| 電源 | 2200W (1+1) Redundant Platinum Level (94%) Power Supplies with PMBus |
支援作業系統 | |
| OS | |
| Ubuntu 18.04 LTS (x64) or later | |
| Ubuntu 20.04 LTS (x64) or later | |
| Red Hat Enterprise Linux 7.6-8.x | |
| Windows Server 2016 | |
| Windows Server 2019 | |
作業環境 | |
| RoHS | 環境規格 |
| Environmental Spec. | |
| Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) | |
| Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) | |
| Operating Relative Humidity: 8% to 90% (non-condensing) | |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) | |
