Form Factor (WxD, mm)
E-ATX
304.8 x 330.2 Processor Supported
AMD EPYC™ 9005 Series Processors
AMD EPYC™ 9004 Series Processors Single processor, cTDP up to 500W Socket
1 x LGA 6096
Socket SP5 Chipset Description
System on Chip
Memory Type
24 x DIMM slots
DDR5 memory supported 12-Channel memory architecture AMD EPYC™ 9005: RDIMM: Up to 5200 MT/s (1DPC) RDIMM: Up to 4400 MT/s (1R 2DPC), 4000 MT/s (2R 2DPC) AMD EPYC™ 9004: RDIMM: Up to 4800 MT/s (1DPC), 3600 MT/s (2DPC) Integrated Network
2 x 10Gb/s LAN (1 x Broadcom® BCM57416)
- Support NCSI function 1 x 10/100/1000 Mbps Management LAN Integrated Video Controller
Integrated in Aspeed® AST2600
- 1 x VGA port Integrated Audio Controller
N/A
Storage Interface
MCIO:
2 x MCIO 8i for 4 x Gen5 NVMe or 16 x SATA 3 x MCIO 8i for 6 x Gen5 NVMe 1 x MCIO 8i for 2 x Gen4 NVMe M.2: 1 x M.2 (2280/22110), PCIe Gen4 x4 Support RAID Function
N/A
PCIe Expansion Slots
Slot_7: PCIe x16 (Gen5 x16)
Slot_6: PCIe x16 (Gen5 x16) Slot_4: PCIe x16 (Gen5 x16) Slot_3: PCIe x16 (Gen5 x16) 2 x MCIO 8i (PCIe Gen5 x8 or SATA) [1][2] 3 x MCIO 8i (PCIe Gen5 x8) [1] 1 x MCIO 8i (PCIe Gen4 x8) [1] Please refer to the optional parts for qualified cables to ensure Gen5 signal quality. [2] The connector supports SATA by default. To enable the other option, please refer to the manual and adjust the settings in the BIOS. 歡迎您使用 上伊美辦公用品 的詢價服務！
