Form Factor | 2.5” |
---|---|
Capacity | 480GB - 1.92TB |
Interface | SATA III |
Flash Type | 112L 3D eTLC |
Dimensions (L x W x H) | 100 x 70 x 7 mm |
Sequential Read (Max*) | 550MB/s |
Sequential Write (Max*) | 380MB/s |
Operating Temperature (Standard) | 0°C to 70°C |
Operating Temperature (Industrial) | -40°C to 85°C |
Operating Temperature (Extended) | - |
Operating Voltage | 5V |
Power Consumption | 2.2W |
Shock Resistance | 1500G/0.5ms, Half Sine Wave |
Operating Humidity | 5%-95% RH, non-condensing |
Vibration Resistance | 20G (20-2000Hz) |
Technologies | Power Loss Protection (PLP), TCG OPAL 2.0, LDPC ECC, RAID Engine, Wear Leveling, DRAM Buffer, SLC Cache, TRIM Command, Thermal Throttling, S.M.A.R.T. Monitor, End-to-end Data Path Protection, ESD Support (IEC/EN 61000-4-2 level 4) |
