E-ATX
305W x 330D mm Processor Supported
2nd Generation Intel® Xeon® Scalable Processors
1st Generation Intel® Xeon® Scalable Processors Dual processor, TDP up to 205W Note: If only 1 CPU is installed, some PCIe or memory functions might be unavailable. Socket
2 x LGA 3647
Socket P Recommended CPU cooler: Dynatron B5 Chipset Description
Intel® C622
Memory Type
16 x DIMM slots
DDR4 memory supported only 6-channel memory architecture RDIMM up to 128GB supported LRDIMM up to 128GB supported Supports Intel® Optane™ DC Persistent Memory (DCPMM) Memory speed: 2933/2666/2400/2133 MT/s Maximum verified DCPMM configuration: *Ambient temperature 35°C *2nd Generation Intel® Xeon® Scalable Processors (205W) *DCPMM 256GB x4 DCPMM installation locations: DIMM_P0_(A1, D1) DIMM_P1_(G1, J1) Note: 1. 2933 MT/s for 2nd Generation Intel® Xeon® Scalable Processors only. 2. Intel® Optane™ DC Persistent Memory for 2nd Generation Intel® Xeon® Scalable Processors only. 3. The maximum number of DCPMM that can be installed is based on a maximum operating (ambient) temperature of 35°C. 4. To enquire about installing a greater number of DCPMM, please consult with your GIGABYTE technical or sales representative. Integrated Network
2 x 10Gb/s LAN ports (1 x Intel® X557-AT2)
2 x 1Gb/s LAN ports (2 x Marvell® 88E1514) 1 x 10/100/1000 Mbps Management LAN Integrated Video Controller
Integrated in Aspeed® AST2500
- 1 x VGA port Integrated Audio Controller
N/A
Storage Interface
CPU_1:
- 2 x SlimSAS connectors for 2 x Gen3 NVMe PCH: - 3 x SlimSAS connectors for 12 x SATA 6Gb/s - 2 x SATA 6Gb/s ports supporting SATA DOM Support RAID Function
Intel® SATA RAID 0/1/10/5
Expansion Slot
