Form Factor | M.2 2280 |
---|---|
Capacity | 480GB - 1.92TB |
Interface | PCIe Gen4x4 |
Flash Type | 3D eTLC |
Dimensions (L x W x H) | 80 x 22 x 2.25mm |
Sequential Read (Max*) | 7000MB/s |
Sequential Write (Max*) | 6200MB/s |
Operating Temperature (Industrial) | - |
Operating Temperature (Standard) | 0ºC to 70ºC |
Operating Temperature (Extended) | - |
Operating Voltage | 3.3V |
Power Consumption | 8W |
Shock Resistance | 1500G/0.5ms |
Operating Humidity | 5%-95% RH, non-condensing |
Vibration Resistance | 20G (20-2000Hz) |
Technologies | LDPC ECC, RAID Engine, Wear Leveling, SLC Cache, DRAM Buffer, TRIM command, Thermal Throttling, S.M.A.R.T. Monitor, AES 256-bit Data Encryption, TCG OPAL 2.0, End-to-End Data Path Protection,ESD Support (IEC/EN 61000-4-2 level 4) |
